Ductile iron pipes class k9 for drinking water

The ductile iron materia features similar mechanical properties with carbon steel such as highmechanical strength,good ductility,and the same anti-corrosion performance as cast iron.Therefore,it has gradually become the world's most safe and reliable pipes and fittings in the field of watersupply and drainage.

Classification :

Ductile iron pipe

+8619963884528

sales13@baotecn.com

E-mail

PRODUCT DETAILS

Product Details
Ductile iron pipes refer to pipes that are cast by high-speed centrifugal casting using a centrifugal ductile iron machine after adding nodulizing agent to cast molten iron above No. 18. They are referred to as ductile iron pipes, ductile iron pipes and ductile cast pipes. It is mainly used for the transportation of tap water and is an ideal material for tap water pipelines.

Technical Specification of Ductile lron Pipes and Fittings
The ductile iron materia features similar mechanical properties with carbon steel such as highmechanical strength,good ductility,and the same anti-corrosion performance as cast iron. Thereforeit has gradually become the world’s most safe and reliable pipes and fittings in the field of watersupply and drainage. Jiugang Steel (Qingdao) Company Limited provides ductile iron pipes and fittings ranging fromDN80mm-DN2600mmin accordance with ISO2531/EN545/598 or GB13295.

Product parameters

Standard	Product	Nominal Diameter DN(mm)	Tensile Strength N/mm2	Yield Strength N/mm2	Elongation%	Hardness HB
ISO2531/EN545/GB13295	Ductile lron Pipes	DN80-1000mm	≥420	≥300	10	≤230
	Ductile lron Pipes	DN1100-2600mm	≥420	≥300	7	≤230
	Ductile lron Fittings	DN80-2600mm	≥420	≥300	5	≤250

Standard of Hydrostatic Testing Pressure (Class K9)

Standard	Product	Nominal Diameter DN(mm)	Testing Pressure(Bar)	Time( second)
ISO2531/EN545/GB13295	Ductile lron Pipes	DN80-300mm	50	≥10
		DN350-600mm	40
		DN700-1000mm	32
		DN1100-2000mm	25
		DN2200-2600mm	18
	Ductile lron Fittings	DN80-300mm	25	≥10
		DN350-600mm	16
		DN700-2600mm	10

Transaction screenshot and Packing and shipping

Baote Steel (Shandong) Group Co., Ltd. Specializing in the production of centrifugal ductile iron pipes and supporting fittings. The annual output of ductile iron pipe is 300,000 tons,

CUSTOMER VISIT

Our country is an international steel trade hub. We will connect China's steel resources with world trade demand through high-quality products in a fast, stable and low-cost way. Work with global partners to develop together and achieve win-win cooperation!

CUSTOMER FEEDBACK

The company has specially built a professional international trade service team with a sales network all over the world. With many advantages, we cooperate with customers in North America, South America, Europe, Southeast Asia, the Middle East and Africa, and have spread all over Peru

FACTORY WORKSHOP

The company is equipped with a complete product production line. Cutting machines, bending machines, punches, water jet cutting machines, polishing machines, shearing machines, wire drawing machines and other professional equipment are complete.

factory

PARTNER

APPLICATION AREAS

Precision Machining

Logistics and freight

Port Terminal

Factory processing

Shipbuilding

Aerospace

Transportation

Construction

FAQ

Q8: How do you make our business long-term and good relationship ?

A: 1.We keep good quality and competitive price to ensure our customers' benefit. 2.We respect every customer as our friend and we sincerrly do business and make friends with them, no matter where they come from.

Q7:Can we get the some samples?Any charges?

A:Yes,you can get available samples in our stock.Free for real samples,but customers need to pay the freight cost.

Q6:How can we get the offer?

A:Please offer the specification of the product,such as material,size,shape,etc.So wecan give the best offer.

Q5: How long is your delivery time?

A: Generally it is 7-14 days if the goods are in stock. or it is 25-45 days if the goods are not in stock, it is according to quantity.

Q4: Can you arrange the shipment?

A: Sure, we have permanent freight forwarder who can gain the best price from most ship company and offer professional service.

Q3: Do you have quality control?

A: Yes, we have gained BV, SGS authentication.
